Thick Bottom PETG Bottle Manufacturing Case: JHD-370D Solution
| Customer Nation: Hong Kong | Industry: Cosmetic Packaging | Resin: PETG |
| Machine Model: JHD-370D | Cavities: 2 | Number of station: 2 |
| Actuator Type: Hybrid (with Servo system) | Productivity: 480 pcs/hr | Product type: Thick bottom bottle |
Customer Background
Founded in 1993, this customer is a Tier-1 cosmetic plastic container manufacturer with over 2,500 employees and a massive 90,000-square-meter facility in Southern China. Serving high-end global beauty brands, they require packaging that exudes luxury and quality, often simulating the clarity and weight of glass. Since 2002, they have trusted Jonh Huah's Extrusion Blow Molding (EBM) technology to produce their most challenging designs, achieving a balance between premium aesthetics and manufacturing flexibility.
Technical Challenges
The production of thick-bottom PETG bottles is notoriously difficult. Unlike standard thin-walled containers, thick-bottom designs require precise control over material distribution (parison programming) to avoid "sink marks" or uneven clarity. PETG, a material with a high melt index (MI), demands a very fast and reliable machine response to maintain shape integrity during the blowing process. Furthermore, for high-end cosmetics, the surface finish must be flawless, with no discernible parting lines or optical distortions.
Our Solution
Jonh Huah implemented the JHD-370D Hybrid Blow Molding Machine, specifically customized for PETG applications. The machine’s advanced electronic control system allows for micro-adjustments in parison wall thickness, which is critical for achieving the "glass-like" thick bottom. By utilizing EBM technology instead of more expensive IBM (Injection Blow Molding) or ISBM (Injection Stretch Blow Molding) processes, we provided a much more cost-effective solution. Our EBM machines only require one set of blowing molds and allow for easy weight adjustments via the HMI touch panel, making them ideal for small-batch diversity and frequent product launches.
Results & Testimonials
The transition to Jonh Huah's hybrid system improved the customer's production flexibility, allowing them to handle diverse, low-volume PETG bottle orders with less setup pressure. The customer's team reported that the HMI interface made parameter adjustment easier for technicians, especially when switching between bottle shapes and thick-bottom designs.
Why Choose Jonh Huah?
Jonh Huah stands out for its ability to customize blow molding solutions for high-precision, aesthetic-focused industries like cosmetics. We specialize in servo-driven technologies that offer both the precision needed for luxury packaging and the energy savings required for modern sustainable manufacturing. If you are looking to replace costly traditional molding processes with a more flexible EBM solution, Jonh Huah is your ideal partner. See related cosmetic and packaging cases or contact our technical team for a consultation.
